PHI RPSMLR2 Precision Hardware Inc Power Supply

Images may not represent actual product and finish

Your Price: $452.95

Retail Price:$705.00

You Save:$252.05(36%)

Power Supply, MLR Kit, No Battery Storage

Part Number : PHI_RPSMLR2

Availability: 73 In Stock.

Quantity

PHI RPSMLR2 Precision Hardware Inc Power Supply

Small enclosure, no battery storage.

Certifications:
UL 294
ULC S-319
Input Power: 120 VAC
Input: Fire alarm termination
Output Power:
2 filtered & regulated 24 Volts DC outputs @ 2 Amps
Holding current 200mA
1 filtered & regulated 24 Volts DC auxiliary output @ 0.8 Amps
Output:
2 normal open relay outputs
Outputs can be wired for 2 different modes:
1 second delay prior to relay output
Positive confirmation of latch retraction prior to signaling the operator when used in conjunction with MLR exit device sensor wires
Battery Backup (RPSMLR2BB only):
Built in charger for sealed lead acid or gel batteries
Automatically switches to stand-by if AC fails
Charging current 650mA max
Batteries are not included
Visual Indicators:
AC power, green LED - Indicates presence of AC power
Triggered input, 2 red LEDs - Indicates input activation
Fire alarm interface, green LED - Indicates fire alarm activation
Battery status, red LED - Indicates low battery during AC power failure
Enclosure Dimensions:
RPSMLR2: 12.5"x7.5"x3.25"
RPSMLR2BB: 13.5"x13"x3.25"
Security: Keyed enclosure

Features

Charging current 650mA max
Security: Keyed enclosure
Output Power:
Automatically switches to stand-by if AC fails
Fire alarm interface, green LED – Indicates fire alarm activation
Enclosure Dimensions:
Holding current 200mA
Visual Indicators:
Built in charger for sealed lead acid or gel batteries
Battery Backup: (RPSMLR2BB only)
AC power, green LED – Indicates presence of AC power
Battery status, red LED – Indicates low battery during AC power failure
RPSMLR2BB: 13.5"x13"x3.25"
1 second delay prior to relay output
Input: Fire alarm termination
Input Power: 120 VAC
RPSMLR2: 12.5"x7.5"x3.25"
1 filtered & regulated 24 Volts DC auxiliary output @ 0.8 Amps
Triggered input, 2 red LEDs – Indicates input activation
2 normal open relay outputs
2 filtered & regulated 24 Volts DC outputs @ 2 Amps
Output:
Outputs can be wired for 2 different modes: 1 second delay prior to relay output Positive confirmation of latch retraction prior to signaling the operator when used in conjunction with MLR exit device sensor wires
Batteries are not included
Positive confirmation of latch retraction prior to signaling the operator when used in conjunction with MLR exit device sensor wires

Ship via: Can Ship UPS

Access Type: Power Supply

Alternate Codes: RPSMLR2

Category: Access Control, Alarm Power Supplies, Alarms & Intercom, Burglar Alarms, CCTV Products, Power Supplies, Wire & Power Supplies

Certifications: UL 294

Door Application: Power Supplies

Electrical Option: Motorized Latch Retraction

Input Voltage: 120V

Output Amps: 2 AMPS

Output Volts: 24VDC

Power Supply Type: For Motorized Latch Retraction

Purpose: General

Series: Precision Power Supplies

Subtype: Power Supply

Transformer Output: Up to 5 Amps

Transformer Type: DC

Type: ACCESS CONTROL

Voltage: 24

Voltage/ Amp Rating: 12V DC
